4.30 Motor Control P.C. Board
Chapter 4: Removal, Replacement, and Adjustment Procedures
4. Remove the cover (B).
5. Remove the two screws (D) securing the electronics module cover (E) to
the electronics module (F).
6. Remove the electronics module cover (E).
7. Disconnect the cables on the motor control P.C. board (G).
8. Using the needle nose pliers, pinch the ends of the stand-offs (H) securing
the P.C. board (G) to the electronics module (F).
9. Remove the P.C. board (G).
Replacement
CAUTION:
When handling electronic components, wear an antistatic strap. Failure
to do so could result in component damage.
1. Put on the antistatic strap.
2. Do the removal procedure in reverse order.
3. To make sure the VersaCare™ Bed operates correctly, do the “Function
Checks” on page 2-6.
Page 4 - 96 VersaCare™ Bed Service Manual (MAN333 REV 2)
