4.26 SideCom® Communication System P.C. Board
Chapter 4: Removal, Replacement, and Adjustment Procedures
4.26 SideCom® Communication System P.C. Board
Tools required: T25 Torx®
1
screwdriver
1/4" nut driver
Removal
1. Set the brakes.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
2. Unplug the bed from its power source.
3. Remove the six screws (A) securing the power supply cover (B) to the bed
(C) (see figure 4-42 on page 4-84).
4. Remove the power supply cover (B).
5. Disconnect all cables from the SideCom® Communication System P.C.
board (D).
6. Remove the two screws (E) securing the connector cover (F) to the P.C.
board (D).
7. Remove the two screws (G) securing the P.C. board (D) to the bed (C).
4
1. Torx® is a registered trademark of Textron, Inc.
VersaCare™ Bed Service Manual (MAN333 REV 2) Page 4 - 83
