Hilti TE 70-ATC Original Operating Instructions

*2244433*
2244433 ﻋﺮﺑﻲ 135
3ﺍﻟﺸﺮﺡ
3.1ﻧﻈﺮﺓﻋﺎﻣﺔﻋﻠﻰﺍﻟﻤﻨﺘﺞ1
@
ﻏﻄﺎءﺍﻟﺤﻤﺎﻳﺔﻣﻦﺍﻟﻐﺒﺎﺭ
;
ﻇﺮﻑﺗﺮﻛﻴﺐﺍﻷﺩﻭﺍﺕ
=
ﻭﺳﻴﻠﺔﺗﺤﺮﻳﺮﺍﻷﺩﺍﺓ
%
ﻣﺤﺪﺩﺍﻟﻌﻤﻖ)ﻣﻠﺤﻖ(
&
ﻣﻔﺘﺎﺡﺍﺧﺘﻴﺎﺭﺍﻟﻮﻇﻴﻔﺔ
(
ﺗﺜﺒﻴﺖﺍﻹﺯﻣﻴﻞ
)
ﻣﻔﺘﺎﺡﺍﻟﺘﺤﻜﻢ
+
ﺍﻹﺷﺎﺭﺓﺍﻟﻮﻇﻴﻔﻴﺔ
§
ﻣﺒﻴﻦﺍﻟﺨﺪﻣﺔ
/
ﻣﺒﻴﻦﻧﺼﻒﺍﻟﻘﺪﺭﺓ
:
ﻣﻔﺘﺎﺡﻟﻮﺿﻊﻧﺼﻒﺍﻟﻘﺪﺭﺓ
∙
ﻛﺎﺑﻞﺍﻟﻜﻬﺮﺑﺎءﻣﻊﻭﺻﻠﺔﻣﻘﺒﺴﻴﺔﻣﺸﻔﺮﺓ
ﻭﻗﺎﺑﻠﺔﻟﻠﺨﻠﻊ
$
ﺍﻟﻤﻘﺒﺾﺍﻟﺠﺎﻧﺒﻲ
3.2ﺍﻻﺳﺘﺨﺪﺍﻡﺍﻟﻤﻄﺎﺑﻖﻟﻠﺘﻌﻠﻴﻤﺎﺕ
ﺍﻟﻤﻨﺘﺞﺍﻟﻤﺸﺮﻭﺡﻋﺒﺎﺭﺓﻋﻦﻣﻄﺮﻗﺔﻣﺘﻌﺪﺩﺓﺍﻷﻏﺮﺍﺽﻣﺸﻐﻠﺔﺑﺎﻟﻜﻬﺮﺑﺎءﻭﻣﺰﻭﺩﺓﺑﻄﺎﺭﻕﻧﻴﻮﻣﺎﺗﻴﻜﻲ.ﻭﻫﻮﻣﺨﺼﺺ
ﻷﻋﻤﺎﻝﺍﻟﺜﻘﺐﻓﻲﺍﻟﺨﺮﺳﺎﻧﺔﻭﺍﻟﺠﺪﺭﺍﻥ،ﺍﻷﺧﺸﺎﺏﻭﺍﻟﻤﻌﺎﺩﻥ.ﻋﻼﻭﺓﻋﻠﻰﺫﻟﻚﻳﻤﻜﻦﺍﺳﺘﺨﺪﺍﻡﺍﻟﻤﻨﺘﺞﻓﻲﺍﻷﻋﻤﺎﻝ
ﺍﻟﺨﻔﻴﻔﺔﻭﺍﻟﻤﺘﻮﺳﻄﺔﺍﻟﺘﻲﻳﺘﻢﻓﻴﻬﺎﺍﺳﺘﺨﺪﺍﻡﺍﻹﺯﻣﻴﻞﻟﻠﻨﻘﺮﻓﻲﺍﻟﺠﺪﺭﺍﻥﻭﺍﻷﻋﻤﺎﻝﺍﻟﻼﺣﻘﺔﺍﻟﺘﻲﺗﺘﻢﻋﻠﻰﺍﻟﺨﺮﺳﺎﻧﺔ.
◀
ﻳﺠﺐﺃﻻﻳﺘﻢﺍﻟﺘﺸﻐﻴﻞﺇﻻﺑﺎﻟﺘﺮﺩﺩﻭﺍﻟﺠﻬﺪﺍﻟﻜﻬﺮﺑﺎﺋﻲﺍﻟﻤﺬﻛﻮﺭﻳﻦﻋﻠﻰﻟﻮﺣﺔﺍﻟﺼﻨﻊ.
3.3ﺧﺎﺑﻮﺭﺗﺜﺒﻴﺖﻣﺸﻘﻮﻕﻣﻦﺍﻟﺨﻠﻒ
ﺍﻟﻤﻨﺘﺞﻣﺼﻤﻢﻟﺘﺮﻛﻴﺐﺧﻮﺍﺑﻴﺮﺍﻟﻘﻄﻮﻉﺍﻟﺴﻔﻠﻴﺔ.ﺍﻗﺘﺼﺮﻋﻠﻰﺍﺳﺘﺨﺪﺍﻡﺃﺩﻭﺍﺕﺍﻟﺘﺮﻛﻴﺐﺍﻟﻤﻨﺎﺳﺒﺔ!
ﻳﻤﻜﻨﻚﺍﻟﺤﺼﻮﻝﻋﻠﻰﻣﻌﻠﻮﻣﺎﺕﺗﻔﺼﻴﻠﻴﺔﻟﺪﻯﻣﺮﻛﺰHiltiﺍﻟﺬﻱﺗﺘﻌﺎﻣﻞﻣﻌﻪ.
3.4ﺍﻻﺳﺘﺨﺪﺍﻡﺍﻟﺨﺎﻃﺊﺍﻟﻤﺤﺘﻤﻞ
•ﻫﺬﺍﺍﻟﻤﻨﺘﺞﻏﻴﺮﻣﺨﺼﺺﻟﻠﻌﻤﻞﻣﻊﺍﻟﺨﺎﻣﺎﺕﺍﻟﻀﺎﺭﺓﺑﺎﻟﺼﺤﺔ.
•ﻫﺬﺍﺍﻟﻤﻨﺘﺞﻏﻴﺮﻣﻨﺎﺳﺐﻟﻠﻌﻤﻞﻓﻲﺍﻟﺒﻴﺌﺎﺕﺍﻟﺮﻃﺒﺔ.
3.5Active Vibration Reduction
ﺍﻟﻤﻨﺘﺞﻣﺠﻬﻮﺑﻨﻈﺎﻡActive Vibration Reduction (AVR)ﻭﺍﻟﺬﻱﻳﻘﻮﻡﺑﺨﻔﺾﺍﻻﻫﺘﺰﺍﺯﺍﺕﺑﺸﻜﻞﻣﻠﺤﻮﻅ.
3.6ATC
ﺍﻟﻤﻨﺘﺞﻣﺰﻭﺩﺑﺨﺎﺻﻴﺔﺍﻹﻳﻘﺎﻑﺍﻹﻟﻜﺘﺮﻭﻧﻲﺍﻟﺴﺮﻳﻊATC (Active Torque Control(.
ﻓﻲﺣﺎﻟﺔﺇﻋﺎﻗﺔﺃﺩﺍﺓﺍﻟﺸﻐﻞﺃﻭﺍﻧﺤﺼﺎﺭﻫﺎ،ﻓﺈﻥﺍﻟﻤﻨﺘﺞﻳﺪﻭﺭﺑﺸﻜﻞﻣﻔﺎﺟﺊﻋﻠﻰﻧﺤﻮﻏﻴﺮﻣﺤﻜﻮﻡﻓﻲﺍﻻﺗﺠﺎﻩ
ﺍﻟﻤﻌﺎﻛﺲ.ﻭﺗﺘﻌﺮﻑﻭﻇﻴﻔﺔATCﻋﻠﻰﻫﺬﻩﺍﻟﺤﺮﻛﺔﺍﻟﻤﻔﺎﺟﺌﺔﻟﻠﺪﻭﺭﺍﻥﺑﺎﻟﻤﻨﺘﺞﻭﺗﻘﻮﻡﺑﺈﻳﻘﺎﻑﺍﻟﻤﻨﺘﺞﻋﻠﻰﺍﻟﻔﻮﺭ.

Hilti TE 70-ATC Specifications

General

Single impact energy	11.5 J
Active Torque Control (ATC)	Yes
Vibration reduction	Yes
Drilling Diameter Range (Hammer Drill Bits)	12 - 40 mm
Chuck Type	TE-Y (SDS Max)
Dust Removal Module Available	Yes
Rated Voltage	230 V
Impact Energy	11.5 J
Power Output	900 W
Voltage	220-240 V
Frequency	50-60 Hz
Tool Holder	TE-Y (SDS Max)
Cord Length	4 m
Drilling Diameter Range (Core Bits)	40 - 150 mm
Working Mode	Hammer drilling, Drilling
Width	126 mm
