4.3 Setting the Test Fre quency
────────────────────────────────────────────────────
4.3.1 Control Screen Sequence
Input using the
numeric keypad
Input using the
digit keys
Initial screen
Menu screen
Frequency setting screen
Digit screenTen key screen
Initial screen
4.3 Setting the Test Frequency
Sometimes the value for the test frequency should be changed according to
the type of sample being tested.
There are two types of method for inputting the frequency for testing.
Either of two different screens can be selected, according to which of these
two input methods is to be used. These two screens are called the Ten key
screen and the Digit screen.
The Ten key screen
The numerical value for the test frequency is directly
input using the numeric keypad (on the touch panel).
The Digit screen
Each digit of the test frequency can be varied by
using the appropriate up and down keys.
Press the key
Press the key
Select the type of input method for the test
frequency (ten key input or digit variation input)
Input the test frequency
When setting has been completed, press the
key to return to the Initial screen.
