Hioki 3522-50 - Setting the Ranging; Setting AUTO Ranging

49
────────────────────────────────────────────────────
4.6 Setting the Ranging
────────────────────────────────────────────────────
4.6.2 Setting the Ranging
Initial screen
Menu screen
The current test range
is shown in non-
reverse video.
Range keys
HOLD key
AUTO key
Ran
g
in
g
Settin
g
Screen
4.6.3 Setting AUTO Ranging
Ranging setting
screen
1. Press the key on the Initial screen.
The Menu screen will be displayed.
2. Press the key on the Menu screen.
The Ranging setting screen will be displayed.
3. The ranging setting can be either of the following:
AUTO :
The most suitable test range is set automatically.
HOLD :
The test range is fixed, and may only be altered manually.
1. Press this key, and the 3522-50 will automatically be set to the most suitable
test range. At this time, the AUTO key and the key corresponding to the
current test range will be shown in non-reverse video.
2. When the setting has been established as above, press the key to return
to the Initial screen.
