4.6 Setting the Ranging
────────────────────────────────────────────────────
4.6.4 Setting the Ranging to HOLD
Ranging setting
screen
Test range
[Ω]
Range of impedance which can be
measured within the accuracy guaranteed
[Ω]
0.1 10.00 m to 99.99 m
1 80.00 m to 999.99 m
10 0.8000 to 9.9999
100 8.000 to 99.999
1k 80.00 to 999.99
10 k 0.8000 k to 9.9999 k
100 k 8.000 k to 99.999 k
1M 80.00 k to 999.99 k
10 M 0.8000 M to 9.9999 M
100 M 8.0000 M to 200.00M
NOTE
1. There are two ways of setting the ranging to HOLD:
1) While AUTO ranging is set, press the key, and then this key will go
into non-reverse video, and the currently most suitable range will be held
fixed.
2) To select a desired test range directly, just press the key corresponding to
that range. Then the key and also this range key will both go into
non-reverse video.
Set the test range according to the combined impedance value of the sample
to be tested and the test cables.
The measurement range is determined according to the test range setting. If
the display for the measured value shows "OVER FLOW" or "UNDER
FLOW", that means that measurement cannot be performed using the
currently set test range. Either you should set AUTO ranging so as to select
the most suitable test range automatically, or you should set a more suitable
test range manually.
