Hioki BT3554 - Options; Model Z5038 0 ADJ Board; Model 9460 Clip Type Lead with Temperature Sensor; Model 9467 Large Clip Type Lead

6
Options
Model Z5038 0 ADJ Board
(For models 9772, L2020, and 9465-10)
Hook and loop fastener is necessary seperately to stick to the carrying case
and use model Z5038.
Model 9460 Clip Type Lead with Temperature Sensor
Resistance, voltage, and temperature can be measured simultaneously with
this lead.
Temperature
sensor
(Red)
(Black)
(Black)
(Red)
Miniplug
(TEMP SENSOR)
Model 9467 Large Clip Type Lead
These can clip the test lead to the measurement target with a thick bar. Four-
terminal measurement can be conducted just by clipping the lead to the target.
Approx.
I
29 mm
Approx. 850 mm
Approx. 250 mm
(Red)
(Black)
(Red)
(Black)
