Hioki BT3554 - 3.3 Adjusting Zero Value (Zero Adjustment); Performing Zero Adjustment Procedure

44
Adjusting Zero Value (Zero Adjustment)
Performing Zero Adjustment
1
Check to ensure that the test
leads are connected properly.
Disconnect any leads connected
to the measurement target.
1
2
(Black) (Red)
Press for at
least 2 sec.
2
Press the 0ADJ key for at least
2 seconds.
This enables the standby state for
acquiring the correction values.
3
While [0AdJ]LVÀDVKLQJVKRUW
the test leads using the zero
adjustment board.
For more information, see
"Shorting Methods for Various
Test Leads" (p. 41).
If the test leads are not shorted
while the display is blinking, it will
result in an error.
Flashes for approx.
10 secs.
For pin type leads
