Hioki BT3554 - 5.2 Storing Data in the Memory; Store Measurement Values

59
Setting Threshold Values for the Comparator
4
&RQ¿UPWKHVHWWLQJV
The voltage warning limit and
[WARNING]ÀDVKHV
5
Set the voltage warning limit.
6
&RQ¿UPWKHVHWWLQJV
Returns to the measurement screen,
with the comparator function turned
on.
The settings are now saved.
 Voltage is determined using absolute values. Comparison is
possible even if the positive and negative electrodes of the
test lead are connected to negative and positive terminals,
respectively. (Data is stored with the sign.)
 If you set the resistance failure limit to a value that is less than
the resistance warning limit as previously set, the warning limit
will be set to the same value as the new failure limit.
1
2
3
4
5
6
7
