Setting Threshold Values for the Comparator
Examples of how to read the comparator output table
Example 1:
If the measured resistance is less than or equal to the resistance
warning limit, and the measured voltage is more than or equal to the
voltage warning limit, [PASS] is displayed.
Example 2:
If the measured resistance is more than the resistance warning
limit and is less than or equal to the resistance failure limit, and
the measured voltage is more than the voltage warning limit,
[WARNING] is displayed and the buzzer sounds.
When the resistance warning limit and resistance failure limit are set to the
same value, the boundary conditions are as shown below:
Resistance
PASS

Resistance
warning limit
=
Resistance
failure limit
<
Resistance
FAIL
