%DVLF6SHFL¿FDWLRQV
8.2 %DVLF6SHFL¿FDWLRQV
0HDVXUHPHQW
LWHPV
 Measurement of battery internal resistance
 Measurement of battery terminal voltage (DC voltage
only)
 Temperature measurement
0HDVXUHPHQW
UDQJH
Resistance measurement: 0.000 m
ȍ
to 3.100
ȍ
(4-range structure)
Voltage measurement: 0.000 V to ±60.00 V
(2-range structure)
7HPSHUDWXUHPHDVXUHPHQW í&WR&
(Single range structure)
0D[LPXPLQSXW
YROWDJH
60 V DC (between the positive and negative
measurement terminals), does not accept AC voltage
input.
0D[LPXPUDWHG
YROWDJHWR
HDUWK
60 V DC (no measurement category)
Anticipated transient overvoltage 330 V (between all
measurement terminals and ground)
0HDVXUHPHQW
PHWKRG
Resistance measurement:
AC 4-terminal method, open-circuit terminal voltage
5 V max.
Measured current:
1.6 mA to 160 mA (Fixed according to the resistance
measurement range)
Temperature measurement:
Platinum temperature sensor (500
ȍ
at 25°C)
A/D conversion method:
'6
type
Display update rate:
3 times/second (resistance, voltage, and temperature
measured as a set)
(UURUYDOXH
GLVSOD\
Constant current fault detection [íííí] display
Disconnection detection [íííí] display
Can be canceled by power-on option.
