Part Names
Part Names
Rotary switch
LCD
Barrier*
Lever
HOLD key
Voltage input terminal
SHIFT key
(Selects function indicated in
blue lettering.)
Operation keys
(p. 9)
Front
(CM3286-01)
Jaw
(p. 12)
Battery cover
Rear
L9257 Connection Cord
Sleeve
Cord
Barrier*
Alligator clip
Connector
(p. 8)
* Do not touch any areas beyond the barrier while the instrument is in use.
