Connecting the Clamp and Clips
Connecting the Clamp and Clips
Clamp
Current direction
Power supply
side
Load
side
Align the current direction mark with
the direction of the current.
Clip (Alligator)
Connect to metal part.
Clip (Magnetic adapter)
Connect to metal part.
(If unable to connect the magnetic adapter so that it sits
perpendicular to the terminal due to the weight of the voltage cord,
connect it at an angle so as to balance it against the weight of the
cord.)
