Hioki CM3286 - Rotary Switch

17
Operation keys
Rotary switch
When functions other than OFF is selected, the instrument turns on.
Select the desired function.
"Phase Detection [Phase Detect]" (p. 38)
• "AC 3-phase measurement (3P3W, balanced) [3PW]" (p. 31)
• "AC 3-phase measurement (3P3W, unbalanced) [3PW]" (p. 32)
• "AC 3-phase measurement (3P4W, balanced) [3PW]" (p. 34)
• "AC 3-phase measurement (3P4W, unbalanced) [3PW]" (p. 35)
• "Single-phase Active Energy Measurement (Integrated Measurement) [Setting Wh]" (p. 40)
• "Single-phase Energy Meter Comparison Function [Setting Wh]" (p. 42)
• "AC single-phase measurement (1P2W) [var VA W]" (p. 29)
• "AC single-phase measurement (1P3W) [var VA W]" (p. 30)
"Current/Voltage Measurement (Frequency) [ ]" (p. 28)
Turns off the instrument.
