Hioki CM3286 - Switching the Information Shown on the Measurement Display

24
Screen / Basic Operation
Switching the information shown on the measurement display
Able to switch using the SHIFT key (Excluding the and functions).
How to use this chart:
(Sub1 display)
FREQ
U
(Main display)
I
RMS
(Sub2 display)
–
(Sub3 display)
I
|PEAK|
(All
indicators
displayed)
Main
display
Sub1
display
Sub3 display
Sub2 display
Rotary switch
Current Voltage
Current (frequency)
Voltage (frequency)
FREQ
I
FREQ
U
I
RMS
U
RMS
–
I
|PEAK|
–
U
|PEAK|
FREQ
I
: Current frequency
I
RMS
: Current RMS value
I
|PEAK|
: Current peak value
FREQ
U
: Voltage frequency
U
RMS
: Voltage RMS value
U
|PEAK|
: Voltage peak value
