29
Power Measurement (Power/Power Factor)
Power Measurement (Power/Power Factor)
AC single‑phase measurement (1P2W)
[var VA W]
1
*
"Switching the information shown on
the measurement display" (p. 24)
If the screen turns red: "Warning
display" (p. 66)
L/R/A
N
Measurement display*
2
Clamp
and clip
Power supply side
Load side
Red
Black
To Next Page
