Hioki CM3286 - Accuracy Tables; AC Current, Voltage, and Power Accuracy

75
Accuracy Table
Accuracy Table
(1) AC Current Measurement
The current RMS (
I
RMS
) and current peak value (
I
|PEAK|
) ranges will change at the same time.
Auto range threshold: Range up: Current RMS value greater than 6000 count
Range down: Current RMS value less than 540 count
AC current RMS
(
I
RMS
)
Range
(Accuracy guarantee
range)
Resolution Accuracy
Display range
45 Hz ≤ f ≤
66 Hz
66 Hz < f ≤
500 Hz
500 Hz < f ≤
1 kHz
6.000 A
(0.060 A to 6.000 A)
0.001 A
±1.3% rdg.
±3 dgt.
±2.0% rdg.
±5 dgt.
±5.0% rdg.
±5 dgt.
0.000 A to 6.000
A
60.00 A
(0.60 A to 60.00 A)
0.01 A
±1.0% rdg.
±3 dgt.
±1.5% rdg.
±5 dgt.
±3.0% rdg.
±5 dgt.
0.00 A to 60.00 A
600.0 A
(6.0 A to 600.0 A)
0.1 A
–
0.0 A to 600.0 A
