47
Single-phase Energy Meter Comparison Function [Setting Wh]
Watt‑hour meter constants default setting value
No.01 to No.10: 1-cycle mode
0.10 kWh to 0.01 kWh: Fixed energy mode
SET No. Setting value
Changing the
setting value
Enable:

Disable: –
SET No. Setting value
Changing the
setting value
Enable:

Disable: –
oFF None (single-phase
energy measurement)

07 300 cyc./1 kWh

01 3200 cyc./1 kWh

08 250 cyc./1 kWh

02 1600 cyc./1 kWh

09 150 cyc./1 kWh

03 1200 cyc./1 kWh

10 125 cyc./1 kWh

04 1000 cyc./1 kWh

0.10 kWh 0.10 kWh –
05 600 cyc./1 kWh

0.05 kWh 0.05 kWh –
06 500 cyc./1 kWh

0.01 kWh 0.01 kWh –
Updated settings are stored by the instrument.
