49
Manual Hold / Auto Hold
Auto hold conditions
Measured value is automatically retained when the following two conditions are satised:
• When the range over which the measured value is uctuating stabilizes within the uctuation range
described in the table in the next page.
• When the measured value exceeds the threshold value described in the table in the next page.
Ο: Held value
Auto hold
e.g.: 100.0 A
Auto hold
e.g.: 99.0 A
Measured
value
Start
End
End
End
Fluctuation range
Fluctuation range
Fluctuation
range
Threshold value
e.g.: 6.0 A
Measurement
Start
Start
Time
If the measured value* (voltage, current, or active power) falls below the threshold value once and the
two conditions are satised again after automatic retaining, the measured value at that point will retain
automatically.
* Either the current RMS value or voltage RMS value for power.
