53
MAX/ MIN/ AVG
e.g.:
During current measurement
Maximum measured value of the current RMS*
1
Maximum measured value's time*
2
*1 The maximum, minimum, and average values for the main display’s measured value is shown.
(However, only the maximum and average values are shown during peak value measurement.
Also, only the maximum and minimum values are shown during zero-cross phase angle measurement.)
*2 Measured value's update time is displayed when maximum or minimum value is shown. Elapsed time
from the start of maximum, minimum, and average function is displayed when present or average value is
shown.
