81
Accuracy Table
Balanced
3-phase/3-
wire active
power (
P
(3P3W)
)
Balanced
3-phase/3-
wire apparent
power (
S
(3P3W)
)
Accuracy ±3.0% rdg. ±10 dgt. (Power factor =1)
Range
conguration
(minimum
resolution)
Current range
6.000 A 60.00 A 600.0 A
Voltage range 600.0 V
7.200 kW
(0.001 kW)
72.00 kW
(0.01 kW)
720.0 kW
(0.1 kW)
The unit [W] is replaced by [VA] for apparent power values.
Balanced
3-phase/3-
wire reactive
power (
Q
(3P3W)
)
Accuracy ±1 dgt. relative to calculation from measured values
Range
conguration
For the above active power range conguration
,
the unit [W] is replaced
by [var].
Balanced
3-phase/3-
wire power
factor
(
PF
(3P3W)
)
Accuracy ±3° ±2 dgt. (Calculated from the balanced 3-phase/3-wire zero-cross
phase angle)
Range
conguration
Regeneration −0.001
Consumption 0.000 to 1.000
Balanced
3-phase/3-
wire zero-
cross phase
angle (
φ
(3P3W)
)*
Accuracy ±3°
Range
conguration
Lead −90.0° to −0.1°
Lag 0.0° to 90.0°
