Installation GREYHOUND Switch
Release
01
04/2016
27
1.6 Ethernet ports
You can connect end devices and other segments to the device and media
module ports using twisted pair cables or optical fibers (F/O).
1.6.1 1/2.5 Gbit/s F/O port
The port allows you to connect network components according to the IEEE
802.3 1000BASE-SX/1000BASE-LX standard.
The port allows you to connect network components according to
IEEE P802.3bz 2.5 Gbit/s.
This port supports:
Full duplex mode
Delivery state:
1/2.5 Gbit/s full duplex when using a Gigabit Ethernet SFP transceiver
1.6.2 100/1000 Mbit/s F/O port
This port is an SFP slot.
The 100/1000 Mbit/s F/O port offers you the ability to connect network
components according to the IEEE 802.3 100BASE-FX/1000BASE-
SX/1000BASE-LX standard.
This port supports:
1000 Mbit/s full duplex
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
State on delivery:
100 Mbit/s full duplex when using a Fast Ethernet SFP transceiver
1000 Mbit/s full duplex when using a Gigabit Ethernet SFP transceiver
1.6.3 100 Mbit/s F/O port
This port is an SFP slot or an ST or DSC socket.
The 100 Mbit/s F/O port offers you the ability to connect network components
according to the IEEE 802.3 100BASE-FX standard.
This port supports:
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
Default setting: Full duplex
Applies to device variants with DSC ports or ST ports:
When connecting the data cables, note the sending and receiving directions.
Sending direction
Receiving direction
