Hirschmann GREYHOUND GMM42 User Manual

58
Installation GREYHOUND Switch
Release 01 04/2016
7 Technical data
7.1 General technical data
7.1.1 Basic device
Dimensions
W × H × D
See “Dimension drawings” on page 62.
Weight 7.93 lb (3.6 kg)
Power supply
Supply voltage
with characteristic
value L
Nominal voltage DC 24 V ... 48 V
48 V... 54 V
Back-up fuse for each voltage
input
Nominal rating:
Characteristic:
6.3 A
slow blow
Connection type 2-pin terminal block
Power supply
Supply voltage
with characteristic
value H
Nominal voltage AC 110 V ... 240 V, 50 Hz ... 60 Hz
Nominal voltage DC 60 V ... 250 V
Back-up fuse for each voltage
input
Nominal rating:
Characteristic:
2.5 A
slow blow
Connection type 3-pin terminal block
Signal contact Nominal value for AC I
max
=2A at U
max
=230V
Nominal value for DC I
max
=2A at U
max
=30V
I
max
=0.2 A at U
max
= 125 V
I
max
=0.1A at U
max
= 250 V
Climatic conditions
during operation
Ambient air temperature
a
Standard
up to 6560 FASL
(2000 m ü. NN)
over 6562 FASL
(2000 m)
+32 °F ... +140 °F
(0 °C ... +60 °C)
+32 °F to +122 °F
(0 °C ... +50 °C)
Extended
b
,
c
up to 6560 FASL
(2000 m ü. NN)
over 6562 FASL
(2000 m)
−40 °F ... +158 °F
(−40 °C ... +70 °C)
−40 °F ... +140 °F
(−40 °C ... +60 °C)
Extended with
conformal coating
b,c
over 6562 FASL
(2000 m)
over 6562 FASL
(2000 m)
−40 °F ... +158 °F
(−40 °C ... +70 °C)
−40 °F ... +140 °F
(−40 °C ... +60 °C)
Humidity 5 % ... 95 % (non-condensing)
Air pressure minimum 700 hPa (+9842 ft; +3000 m)
maximum 1060 hPa (−1312 ft; −400 m)
Climatic conditions
during storage
Ambient temperature −40 °F ... +185 °F
(−40 °C ... +85 °C)
Humidity 5 % ... 95 % (non-condensing)
Air pressure minimum 700 hPa (+9842 ft; +3000 m)
maximum 1060 hPa (−1312 ft; −400 m)
