Hirschmann GREYHOUND GMM42 User Manual

70
Installation GREYHOUND Switch
Release 01 04/2016
 Power consumption/power output
 Scope of delivery
 Order number
Name Maximum
power consumption
Maximum
power output
Basic devices + 1 PSU
GRS1042 AT2Z... 32 W 110 Btu (IT)/h
GRS1142 AT2Z...
GRS1042 6T6Z...
GRS1142 6T6Z...
Power supply units
GPS1-K + 2.5 W 9 Btu (IT)/h
GPS1-C + 3.5 W 12 Btu (IT)/h
GPS3-P + 5.5 W 19 Btu (IT)/h
Media modules
GMM20-XXXXXXXX 10 W 34 Btu (IT)/h
GMM30-XXXXTTTT 6.5 W 22 Btu (IT)/h
GMM32-XXXXTTTT 8.5 W 29 Btu (IT)/h
GMM40-OOOOTTTT 5.5 W 19 Btu (IT)/h
GMM42-OOOOTTTT 7.5 W 26 Btu (IT)/h
GMM40-OOOOOOOO 7.5 W 26 Btu (IT)/h
GMM40-TTTTTTTT 3.5 W 12 Btu (IT)/h
GMM42-TTTTTTTT 5.5 W 19 Btu (IT)/h
Number Article
1× Device
1 × General safety instructions
1 × 2-pin terminal block for signal contact
2 × Bracket
2 × 2-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with characteristic value LL)
2 × 3-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with characteristic value HH)
1 × 2-pin terminal block for the supply voltage
3-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with characteristic value HL)
GREYHOUND Switch 942 135-999
GREYHOUND power supply units 942 136-999
GREYHOUND media modules 942 134-999
Cover panel for media module slot 942 198-001
Cover panel for power supply unit slot 942 198-002
