44
Installation GREYHOUND Switch
Release
01
04/2016
Mounting on a vertical flat surface
Proceed as follows:
Use the pre-mounted brackets as shown below.
Additionally attach 2 brackets to the back of the device.
You obtain the additional brackets as accessories.
See “Accessories” on page 71.
Fasten the device by screwing the brackets to the wall.
The tightening torque is 4.4 lb-in (0.5 Nm).
WARNING
FIRE HAZARD
Install the device in a fire protected shell if you are mounting it vertically.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
