Hirschmann RSP 20 User Manual

Installation RSP 20/25/30/35
Release 08 08/2014
13
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
Item Characteristic Charac-
teristic
value
Description
1 ... 5 Product RSP20 Fast Ethernet switch
RSP25 Fast Ethernet switch with extended redundancy
function
RSP30 Gigabit Ethernet switch
RSP35 Gigabit Ethernet switch with extended redundancy
function
6 (hyphen) –
7 ... 8 Number
Fast Ethernet ports
08 8 ×
11 11 ×
9 ... 10 Number
Gigabit Ethernet ports
00 0 ×
03 3 ×
11 ... 13 Configuration of the
uplink ports
3Z6 3 × SFP slot for 100 Mbit/s connections
twisted pair and F/O
3O6 3 × SFP slot for 100/1000 Mbit/s connections
twisted pair and F/O
14 ... 15 Configuration of the
other ports
TT 8 × RJ45 socket for 10/100 Mbit/s twisted pair
connections
ZT 4 × RJ45 socket for 10/100 Mbit/s twisted pair
connections
4 × SFP slot for 100 Mbit/s connections
twisted pair and F/O
16 (hyphen) –
17 Temperature range S Standard 0 °C ... +60 °C (+32 °F ...
+140 °F)
T Extended −40 °F ... +158 °F (−40 °C ...
+70 °C)
E Extended with
conformal coating
−40 °F ... +158 °F (−40 °C ...
+70 °C)
18 ... 19 Working voltage CC 2 voltage inputs for redundant power supply
Rated voltage range DC
24 V ... 48 V
K9 1 voltage input
Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Rated voltage range DC
60 V ... 250 V
KK 2 voltage inputs for redundant power supply
Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Rated voltage range DC
60 V ... 250 V
Table 1: Device name and product code
