Note: The overall shield of a connected shielded twisted pair cable is
connected to the ground connector on the front panel as a conductor.
2.3.2 Grounding the device
The housing is grounded via the separate ground screw on the bottom left of
the front panel.
The device variants featuring working voltage with the characteristic
value K9 and KK have 1 connection for protective grounding.
The device variants with working voltage characteristic value CC have a
connection for functional grounding.
Ground the device via the ground screw.
