Hirschmann RSP 20 User Manual

Installation RSP 20/25/30/35
Release 08 08/2014
29
2.5.1 Working voltage characteristic value K9
You will find information on the characteristic values here:
“Device name and product code” on page 13
Figure 3: Working voltage characteristic value K9: 3-pin terminal block with screw
locking
For the operating voltage to be connected, perform the following steps:
 Remove the power connector from the device.
 Connect the protective conductor according to the pin assignment on the
device with the clamp.
 Connect the wires according to the pin assignment on the device with the
clamps.
 Fasten the wires connected by tightening the terminal screws.
Type of the voltages
that can be
connected
Specification of the working
voltage
Connections
DC voltage Rated voltage range DC
60 V ... 250 V
Voltage range DC incl.
maximum tolerances
48 V ... 320 V
+/L Plus terminal of the working
voltage
−/N Minus terminal of the working
voltage
Protective conductor
AC voltage Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Voltage range AC incl.
maximum tolerances
88 V ... 265 V, 47 Hz ... 63 Hz
+/L Outer conductor
−/N Neutral conductor
Protective conductor
Table 8: Working voltage characteristic value K9: type and specification of the
working voltage, connections
WARNING
ELECTRIC SHOCK
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
N
L
