Hirschmann RSP 20 User Manual

40
Installation RSP 20/25/30/35
Release 08 08/2014
8 Technical data
 General technical data
Dimensions
W × H × D
RSP 20/25/30/35 See “Dimension drawings” on page 42.
Weight RSP 20/25/30/35-.......TT-S...... approx. 1.2 kg
RSP 20/25/30/35-.......TT-T......
RSP 20/25/30/35-.......TT-E......
approx. 1.5 kg
RSP 20/25/30/35-.......ZT-S...... approx. 1.3 kg
RSP 20/25/30/35-.......ZT-T......
RSP 20/25/30/35-.......ZT-E......
approx. 1.6 kg
Power supply
Working voltage
with the charac-
teristic value CC
Nominal voltage DC 24 V ... 48 V Class 2
Voltage range DC incl.
maximum tolerances
18 V ... 60 V Class 2
Connection type 2-pin terminal block
Power failure bypass > 10 ms at 20.4 V DC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse for each voltage
input
Nominal rating:
Characteristic:
1A
slow blow
Peak inrush current < 4 A
Power supply
Working voltage
with the charac-
teristic value K9
and KK
Nominal voltage AC 110 V ... 230 V, 50 Hz ... 60 Hz
Voltage range AC incl.
maximum tolerances
88 V ... 265 V, 47 Hz ... 63 Hz
Nominal voltage DC 60 V ... 250 V
Voltage range DC incl.
maximum tolerances
48 V ... 320 V
Connection type 3-pin terminal block
Power failure bypass > 10 ms at 98 V AC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
1 A ... 20 A
slow blow
Peak inrush current < 3.5 A
