Installation RSP 20/25/30/35
Release
08
08/2014
21
1.7 Display elements
After the working voltage is set up, the software starts and initializes itself.
Afterwards, the device performs a self-test. During this process, various
LEDs light up.
1.7.1 Device state
These LEDs provide information about conditions which affect the operation
of the whole device.
Applies to software releases before 02.0.00:
LED Display Color Activity Meaning
Power Working voltage None Working voltage is too low
Yellow Lights up Device variants with redundant power
supply:
Working voltage 1 or 2 is on
flashes 4 times
a period
Software update is running. Maintain the
power supply.
Green Lights up Device variants with redundant power
supply:
Working voltages 1 and 2 are on
Device variants with single power supply:
Operating voltage is on
RM Ring Manager None No redundancy configured
Green Lights up Redundancy exists
Flashes 1 time
a period
Device is reporting an incorrect configura-
tion of the RM function
Yellow Lights up No redundancy exists
ACA Storage medium
ACA31
None ACA storage medium not connected
Green Lights up ACA storage medium connected
Flashes 3
times a period
Device writes to/reads from the storage
medium
Yellow Lights up ACA storage medium inoperative
LED Display Color Activity Meaning
Status Device Status None Device is starting and/or is not ready for
operation
Green Lights up Device is ready for operation.
Characteristics can be configured
Red Lights up Device is inoperative
Flashes 1 time
a period
The boot parameters used when the
device has been started differ from the
boot parameters saved.
Start the device again.
Status
RM
ACA
Power
