Installation RSP 20/25/30/35
Release 08 08/2014
 Accessories
Note: Please note that recommended accessories for the products
possibly have different characteristics than the device and thus limit the
application area of the overall system. For example, adding an accessory
having the class of protection IP 20 to a device having the class of protec-
tion IP 65 reduces the class of protection of the overall system to IP 20.
Name Order number
Terminal cable 943 301-001
AutoConfiguration Adapter ACA 31 942 074-001
Network management software Industrial HiVision 943 156-xxx
For device variants with the characteristic value K9 or KK for the
working voltage:
3-pin terminal block (50 pieces) for working voltage
943 845-008
For device variants with the characteristic value CC for the working
voltage:
2-pin terminal block (50 pieces) for working voltage
943 845-009
2-pin terminal block (50 pieces) for signal contact 943 845-010
Power Cord 942 000-001
Dust protection cap (50 pieces) for RJ 45 sockets 943 936-001
Dust protection cap (25 pieces) for RJ 45 slot 943 942-001
Gigabit Ethernet SFP transceiver Order number
M-SFP-TX/RJ45 943 977-001
Note the following for the M-SFP-TX/RJ45 transceiver:
 Can be used with:
- HiOS from software version 03.0.00
- Classic Switch Software from software version 04.1.00
- HiSecOS from software version 01.2.00
Not for use with the following devices:
- SPIDER II
- MSP/MSM
- EES
 Twisted pair ports that are implemented using this transceiver have increased link failure
detection times compared to twisted pair ports that are directly available in the device.
 When using this SFP transceiver, expect increased switching times with the RSTP.
 Cannot be used in combo ports.
M-SFP-SX/LC 943 014-001
M-SFP-SX/LC EEC 943 896-001
M-SFP-MX/LC EEC 942 108-001
M-SFP-LX/LC 943 015-001
M-SFP-LX/LC EEC 943 897-001
M-SFP-LX+/LC 942 023-001
M-SFP-LX+/ LC EEC 942 024-001
M-SFP-LH/LC 943 042-001
M-SFP-LH/LC EEC 943 898-001
M-SFP-LH+/LC 943 049-001
Bidirectional Gigabit Ethernet SFP transceiver Order number
M-SFP-BIDI Type A LX/LC EEC 943 974-001
M-SFP-BIDI Type B LX/LC EEC 943 974-002
