Parameter Values Default values Comment
global PSU alarm PSU 1/2 enabled /
disabled
PSU 1 / 2 enabled
Aging time Aging time in s 300 s
QoS 802.1p mapping VLAN Priority 0 ... 7
Traffic Class 0 ... 3
VLAN Priority
0
1
2
3
4
5
6
7
Traffic Class
1
0
0
1
2
2
3
3
QoS DSCP mapping DSCP value 0 ... 63
Traffic Class 0 ... 3
See “DSCP mapping table” on page 38.
per port Flow control enabled / disabled disabled
Port admin state enabled / disabled enabled
Jumbo frames enabled / disabled disabled Only on GE ports
Broadcast storm
protection
enabled / disabled disabled Ingress filtering
Broadcast storm
threshold
0% ... 100% 100%
Multicast storm
protection
enabled / disabled disabled Ingress filtering
Multicast storm threshold 0% ... 100% 100%
QoS Trust Mode untrusted, trustDot1p,
trustIpDscp
trustDot1 This also includes VLAN 0 mode for
Profinet applications.
Port based priority 0 .. 7 0
Link alarm enabled / disabled disabled
Table 5: Configuration parameters
