38
Installation SPIDER PL
Release
08
09/2018
per TP port Autonegotiation enabled / disabled enabled
Speed 100 Mbit/s, 10 Mbit/s 100 Mbit/s Only if autonegotiation is disabled, no
forced mode 1000 Mbit/s
Duplex mode FDX / HDX FDX Only if autonegotiation is disabled
Autocrossing enabled / disabled enabled Only if autonegotiation is disabled
MDI state MDI-X MDI-X Only if autonegotiation is disabled
EEE enabled / disabled disabled Only for GE ports
per Fiber port Duplex mode FDX / HDX FDX
d2/d10123456
0: 1001233
1: 1001233
2: 1002233
3: 1002233
4: 101223
5: 101223
6: 101223
7: 101223
8: 001233
9: 001233
Table 6: DSCP mapping table
Parameter Values Default values Comment
Table 5: Configuration parameters
