Projector installation
26
Projector installation
Installing or removing the optional lens
Caution: Do not shake or place excessive pressure on the projector or the lens components as
the projector and lens components contain precision parts.
Caution: Before removing or installing the lens, be sure to turn off the projector, wait until the
cooling fans stop, and turn off the main power switch.
Caution: Do not touch the lens surface when removing or installing the lens.
Caution: Keep ngerprints, dust or oil off the lens surface. Do not scratch the lens surface.
Caution: Work on a level surface with a soft cloth under it to avoid scratching.
Caution: If you remove and store the lens, attach the lens cap to the projector to keep off dust
and dirt.
Installing the new lens
Remove both end caps from the lens.
Note: Removal of the plastic body cap before inserting a lens for the rst time.
1. Align the ange and correctly position at the 11 o’clock position as shown in the picture.
Flange
Note: Flange must be positioned at the 11 o'clock position, direction as shown in the picture.
2. Rotate the lens clockwise until you feel it click into place.
