Communication settings
87
Command control settings
[TCP #23]
1. Command format
Same as RS-232C communication, refer to RS-232C Communication command format.
2. Response code / Error code (“h” shows hexadecimal)
Four of the response / error code used for TCP#23 are the same as RS-232C Communication
(1)~(4).
(1) ACK reply: 06h
Refer to RS-232C communication.
(2) NAK reply: 15h
Refer to RS-232C communication.
(3) Error reply: 1Ch + 0000h
Refer to RS-232C communication.
(4) Data reply: 1Dh + xxxxh
Refer to RS-232C communication.
Note: Operation cannot be guaranteed when the projector receives an undened command or
data.
Note: Provide an interval of at least 40ms between the response code and any other code.
Note: Commands are not accepted during warm-up.
Communication command table
1st Layer 2nd Layer 3rd Layer 4th Layer Selections
Hitachi Commands
Operation
Header Data (7 bytes) Command Data (6 bytes)
Description
Header
Code
Packet
Data
Size
CRC Action Type
Setting
Code
Display Mode
Presentation
Set
Presentation BE EF 03 06 00 B3 CB 01 00 BA 30 51 00
Bright High Bright BE EF 03 06 00 23 CA 01 00 BA 30 50 00
Game Sports BE EF 03 06 00 D3 F6 01 00 BA 30 03 00
Movie Cinema BE EF 03 06 00 B3 F7 01 00 BA 30 01 00
Vivid Photo BE EF 03 06 00 73 F5 01 00 BA 30 05 00
TV Video BE EF 03 06 00 43 CB 01 00 BA 30 52 00
sRGB Natural BE EF 03 06 00 23 F6 01 00 BA 30 00 00
DICOM SIM 
DICOM SIM.
DICOM SIM. BE EF 03 06 00 73 C6 01 00 BA 30 41 00
User1 USER-1 BE EF 03 06 00 E3 FB 01 00 BA 30 10 00
User2 USER-2 BE EF 03 06 00 73 FA 01 00 BA 30 11 00
Get BE EF 03 06 00 10 F6 02 00 BA 30 00 00
Brightness 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 03 20 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 EF D2 04 00 03 20 00 00
Decrement BE EF 03 06 00 3E D3 05 00 03 20 00 00
Get BE EF 03 06 00 89 D2 02 00 03 20 00 00
Contrast 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 04 20 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 9B D3 04 00 04 20 00 00
Decrement BE EF 03 06 00 4A D2 05 00 04 20 00 00
Get BE EF 03 06 00 FD D3 02 00 04 20 00 00
Computer
Horizontal Position
-5~5 (depend on
Auto Sync)
Set 0 - 10 BE EF 03 06 00 [*1] 01 00 01 21 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 0A
00 (Max)
Increment BE EF 03 06 00 97 82 04 00 01 21 00 00
Decrement BE EF 03 06 00 46 83 05 00 01 21 00 00
Get BE EF 03 06 00 F1 82 02 00 01 21 00 00
Vertical Position
-5~5 (depend on
Auto Sync)
Set 0 - 10 BE EF 03 06 00 [*1] 01 00 00 21 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 0A
00 (Max)
Increment BE EF 03 06 00 6B 83 04 00 00 21 00 00
Decrement BE EF 03 06 00 BA 82 05 00 00 21 00 00
Get BE EF 03 06 00 0D 83 02 00 00 21 00 00
Frequency  H Phase
0~31
Set 0 - 31 BE EF 03 06 00 [*1] 01 00 03 21 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 1F
00 (Max)
Increment BE EF 03 06 00 2F 83 04 00 03 21 00 00
Decrement BE EF 03 06 00 FE 82 05 00 03 21 00 00
Get BE EF 03 06 00 49 83 02 00 03 21 00 00
Tracking -5~5
Set 0 - 10 BE EF 03 06 00 [*1] 01 00 02 21 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 0A
00 (Max)
Increment BE EF 03 06 00 D3 82 04 00 02 21 00 00
Decrement BE EF 03 06 00 02 83 05 00 02 21 00 00
Get BE EF 03 06 00 B5 82 02 00 02 21 00 00
