Hitachi LP-WU6600 - 3 D Timing Format Compatibility

Specications
82
Signal
Format
Resolution
H Freq.
KHz
Frame
Rate Hz
PCLK
MHZ
5 BNC
VGA
RGBHV
5 BNC
RGBHV
DVI-D
HDMI / HDBaseT
Remark
RGB
YUV
8bit 10bit 12bit
HDTV
1035i 33.750 60 74.250 X X X X X X X X
1080i 28.125 50 74.250 X X X X X X X X
1080i 33.716 59.94 74.176 X X X X X X X X
1080i 33.750 60 74.250 X X X X X X X X
720p 37.500 50 74.250 X X X X X X X X
720p 44.955 59.94 74.176 X X X X X X X X
720p 45.000 60 74.250 X X X X X X X X
1080p 26.973 23.98 74.176 X X X X X X X X
1080p 27.000 24 74.250 X X X X X X X X
1080p 28.125 25 74.250 X X X X X X X X
1080p 33.716 29.97 74.176 X X X X X X X X
1080p 33.750 30 74.250 X X X X X X X X
1080p 56.250 50 148.500 X X X X X X X X
1080p 67.433 59.94 148.352 X X X X X X X X
1080p 67.500 60 148.500 X X X X X X X X
3D timing format
Standard
Resolution V-Freq
(Hz)
V-Total H-Freq
(kHz)
HDBaseT
(*1)
HDMI1/2
(*1)
DVI-D
(*2)
Remarks
720p50 Frame Packing 1280x720 50 1470 37.5 √ √ *3
720p59 Frame Packing 1280x720 59.94 1470 44.96 √ √ *3
720p60 Frame Packing 1280x720 60 1470 45 √ √ *3
720p50 Top-and-Bottom 1280x720 50 750 37.5 √ √ √ *3
720p59 Top-and-Bottom 1280x720 59.94 750 44.96 √ √ √ *3
720p60 Top-and-Bottom 1280x720 60 750 45 √ √ √ *3
1080p23 Frame Packing 1920x1080 23.98 2205 26.97 √ √
1080p24 Frame Packing 1920x1080 24 2205 27 √ √
1080i50 Side-by-Side (Half) 1920x1080 50 1125 56.25 √ √ √ *3
1080i59 Side-by-Side (Half) 1920x1080 59.94 1125 67.43 √ √ √ *3
1080i60 Side-by-Side (Half) 1920x1080 60 1125 67.5 √ √ √ *3
1080p50 Side-by-Side (Half) 1920x1080 50 1125 56.25 √ √ √ *3
1080p59 Side-by-Side (Half) 1920x1080 59.94 1125 67.43 √ √ √ *3
1080p60 Side-by-Side (Half) 1920x1080 60 1125 67.5 √ √ √ *3
1080p50 Top-and-Bottom 1920x1080 50 1125 56.25 √ √ √ *3
1080p59 Top-and-Bottom 1920x1080 59.94 1125 67.43 √ √ √ *3
1080p60 Top-and-Bottom 1920x1080 60 1125 67.5 √ √ √ *3
1080p50 Frame Sequential 1920x1080 50 1125 56.25 √ √ √ *3
1080p59 Frame Sequential 1920x1080 59.64 1125 67.43 √ √ √ *3
1080p60 Frame Sequential 1920x1080 60 1125 67.5 √ √ √ *3
*1: Base on IT6802 chip specication
*2: Base on IT6633 chip specication
*3: Frame drop at scaler and frame doubling at formatter
