MULTI-STEP SPEED COMMAND
Multi-Step speed command can be configured up to 16 speeds. Only use multi-step speed command when speed control greater than
3-steps -step speed command, 4 inputs as a binary combination of 0 (OFF) and 1 (ON) will determine the
f the
multi-step speed command.
NOTE – The multi-step speed command steps outside of the internal program to determine the speeds during normal operation.
Please make sure that Ab110 & UE--12 to match the high-speed
-speed binary operation.
Speed Control Method
Parameters
Values
Multi-Step Speed Command
UE-18 6
Input Speed Source
AA101 7 = Keypad
Multi-Step Digital Inputs
Digital Input 3 | CA-03 03 = CF1
Digital Input 4 | CA-04 04 = CF2
Digital Input 6 | CA-06 05 = CF3
Digital Input 8 | CA-08 06 = CF4
Set Encoder Limits to Parameters
UE-33 2
Muti-Step Speed
CF4
CF3
CF2
CF1

Parameter
NOTE
1
st
speed
OFF OFF OFF OFF Ab110
Set UE-11 to
match Ab110
2
nd
speed
OFF OFF OFF ON Ab-11
Set UE-12 to
match the
highest

set in the
multi-step
3
rd
speed
OFF OFF ON OFF Ab-12
4
th
speed
OFF OFF ON ON Ab-13
5
th
speed
OFF ON OFF OFF Ab-14
6
th
speed
OFF ON OFF ON Ab-15
7
th
speed
OFF ON ON OFF Ab-16
8
th
speed
OFF ON ON ON Ab-17
9
th
speed
ON OFF OFF OFF Ab-18
10
th
speed
ON OFF OFF ON Ab-19
11
th
speed
ON OFF ON OFF Ab-20
12
th
speed
ON OFF ON ON Ab-21
13
th
speed
ON ON OFF OFF Ab-22
14
th
speed
ON ON OFF ON Ab-23
15
th
speed
ON ON ON OFF Ab-24
16
th
speed
ON ON ON ON Ab-25
