CONFIGURING SPEEDS / FREQUENCIES
example is 15.25 Hz = 1525).

o
prevent motor overheating.
Speed Control Method
Speeds
Speed Parameters
Example Values
2-Step
(factory default)
1
st
speed / low speed UE-11 1000 (10.00 Hz)
2
nd
speed / high speed UE-12 6000 (60.00 Hz)
2-Step Infinitely Variable
1
st
speed / low speed UE-11 1000 (10.00 Hz)
2
nd
speed / high speed UE-12 6000 (60.00 Hz)
3-Step
1
st
speed / low speed UE-11 1000 (10.00 Hz)
2
nd
speed UE-12 3500 (35.00 Hz)
3
rd
speed / high speed UE-13 6000 (60.00 Hz)
3-Step Infinitely Variable
1
st
speed / low speed UE-11 1000 (10.00 Hz)
n/a n/a n/a
3
rd
speed / high speed UE-13 6000 (60.00 Hz)
0-10V / 4-20mA
1
st
speed / low speed UE-11 1000 (10.00 Hz)
2
nd
speed / high speed UE-12 6000 (60.00 Hz)
Auto-Speed
Auto-Speed UE-14 9000 (90.00 Hz)
4 – 16-Step
See Multi-Step Speed Command.
