Installation method for the right footrest:
The right pedal is marked with "R" on the pedal shaft, first turn the pedal shaft clockwise by hand and
pre-tighten it.
Insert the right-hand crank with the gear plate, then tighten it by turning the open-end spanner No. 15
clockwise.
How to install the left footrest:
The left pedal is marked with "L" on the pedal
shaft, first turn the pedal shaft counterclockwise
by hand and pre-torque it into the left crank.
Then tighten it with an open-end spanner No. 15
by turning it counterclockwise.
5. Seat pack tail light installation
1. Pull the seat tube adjustment quick release
trigger in the direction shown
2. Position the tail light in the direction of the
diagram, pull the rubber puller in the direction of the
arrow and fasten it.
