2. Headlight installation
3. Front wheel mounting
1. Pre-install the headlight
and fender on the fork with
the headlight fixing screws.
2. Tighten the screws with
the hexagonal spanner No. 5
in the 16-in-1 tool.
3. Screw the nut on.
1. Loosen the nut in the figure with an
open-end spanner No. 15 in the
16-in-1 tool and remove the support
shaft.
2. Fit the front wheel into the fork hook and claw and snap it into place.
Note: The disc brake pads are placed inside the disc brake.
Deutsch / English / Français / Español / Italiano / Nederlands / Polski
-56-
