Scanreco G2 radio remote control system
18
HMF Technical Service Department
Rev.: 20-13
Signal name
Signal source
Description of signal
REGEN JIB
Activation of the ON push button on the
remote control box.
High signal for the regeneration valve on the "jib
- up" function (regeneration), when the load
moment of the crane is less than 50 %.
REGEN EXT
Activation of the ON push button on the
remote control box.
High signal for the regeneration valve on the
"extension - out" function (regeneration), when
the load moment of the crane is less than 50 %.
REGEN BOOM JIB
Activation of the ON push button on the
remote control box.
High signal for the regeneration valve on the
"boom - up" and "jib - up" function
(regeneration), when the load moment of the
crane is less than 50 %.
ENGINE FULL
Activation of tumbler switch no. 1 - to
the left - on the remote control box.
---------------------------------------
Activation of tumbler switch no. 1 - to
the right - on the remote control box.
High signal for the engine control of the truck. In
case of activation, the number of revolutions is
increased to a predetermined value.
Requires selection of Engine in Features.
--------------------------------------------------
High signal for the engine control of the truck,
when a crane function is activated by the remote
control lever.
When the remote control lever is in neutral
position, the signal goes low after a certain
interval: Engine timeout (1.1.1.1.1.9.6).
Requires selection of Engine in Features.
ENGINE RPM M
Activation of tumbler switch no. 3 - to
the right - on the remote control box.
High signal for the engine control of the truck.
The number of revolutions is reduced stepwise
by each activation of the tumbler switch.
ENGINE RPM P
Activation of tumbler switch no. 3 - to
the left - on the remote control box.
High signal for the engine control of the truck.
The number of revolutions is increased stepwise
by each activation of the tumbler switch.
LIGHT
Activated by green press button
(holding) on the RCL 5300 or green
press button on the remote control box.
Signal for a relay that powers a spotlight. The
signal is permanently coded in the RCL 5300
application program.
PVSK DMP
2 x activating the yellow push button
(pos. 7) on the remote control box or
the RCL 5300 indicator panel.
High signal for the PVEO electric activation on
the PVSK module of the Danfoss PVG 32
control valve - change to crane mode - by the
first activation of a crane function with a remote
control lever, when the RCL safety system
allows the crane to work.
PVSK SHIFT
2 x activating the yellow push button
(pos. 7) on the remote control box or
the RCL 5300 indicator panel.
High signal for the PVEO electric activation on
the PVSK module of the Danfoss PVG 32
control valve that changes to stabilizer mode.
HORN
Activation of the ON push button on the
remote control box or the OPT press
button on the RCL 5300 (kept down).
High signal for a horn fitted on the crane.
FLASH
Activation of the green press button
(pos. 6) when starting up the RCL
system.
High signal for the alarm flash. E.g. for LED
band on the stabilizer legs.
ENGINE START
Activation of tumbler switch no. 2 - to
the left - on the remote control box.
High signal for the engine control of the truck.
Starting up the engine.
ENGINE STOP
Activation of tumbler switch no. 2 - to
the right - on the remote control box.
High signal for the engine control of the truck.
Stop of the engine.
EVS BYPASS
Activation of the key switch from the
"EVS on" position to the "2 ZONE LMB
on" position.
High signal when the key switch is in the "2
ZONE LMB on" position. In this position you
change from the EVS system to the 2-stage
LMB system.
