HMF Scanreco G2 - Page 19

Scanreco G2 radio remote control system
19
HMF Technical Service Department
Rev.: 20-13
Signal name
Signal source
Description of signal
WINCH PARK
Activation of the yellow push button
on the remote control box.
High signal for changeover of a solenoid
valve in the hydraulic system for winch, so
that the winch can be moved up into and
down from stowing position.
FJ EX 1
Simultaneous activation of tumbler
switch no. 10 and tumbler switch no.
3 to the left.
High signal for the solenoid valve for
change between Fly-Jib and grab, when
the lever configuration "Fly Jib Shift Grab"
is activated in "Lever Config.".
FJ EX 2
Simultaneous activation of tumbler
switch no. 10 and tumbler switch no.
3 to the right.
High signal for the solenoid valve for
change between Fly-Jib and rotator, when
the lever configuration "Fly Jib Shift
Rotator" is activated in "Lever Config.".
STB LOW
Signal by 0-50 % activation of a
remote control lever in stabilizer
mode.
High signal for the solenoid valve for low
stabilizer speed (1
st
version of Odin and
Thor stabilizer valve block).
STB HIGH
Signal by 50-100 % activation of a
remote control lever in stabilizer
mode.
High signal for the solenoid valve for high
stabilizer speed (1
st
version of Odin and
Thor stabilizer valve block).
STB DIR A
Signal by activation of a remote
control lever forwards - in stabilizer
mode.
High signal for the directional valve of the
stabilizer control valve for control of oil flow
for "stabilizer legs - up" and "stabilizer
beams - retract".
STB DIR B
Signal by activation of a remote
control lever backwards - in stabilizer
mode.
High signal for the directional valve of the
stabilizer control valve for control of oil flow
for "stabilizer legs - down" and "stabilizer
beams - extend".
STB 1 - STB 16
Digital signal by activation of a
remote control lever - in stabilizer
mode.
The digital signals control the functions of
the stabilizer control valve (PWM
activations or ON-OFF activations) for
cylinders for stabilizer legs and stabilizer
beams.
Ex.1 - Ex.16
Proportional signal (can be defined
as digital or digital hold) by activation
of a remote control lever - both in
crane mode and stabilizer mode.
The proportional signals (PWM activations)
can operate the control valve functions for
optional extras on the crane or on a
vehicle.
LEV COL 1-12
=
Lever setup 1 - 12
(1.1.1.1.2.8.1-12)
Activation of a tumbler switch or a
combination of tumbler switches.
When activating the tumbler switch, a
signal appears for changeover to another
configuration of the remote control levers. If
for example the crane has radio remote
control of stabilizers, the remote control
levers change function from operation of
crane functions to operation of stabilizer
functions when pushing the yellow press
button twice (2 x yellow) (change between
crane mode and stabilizer mode). By
means of configuration/activation of
different tumbler switches it is possible to
change between up to 12 different types of
operation from the remote control levers.
Led Run
The same signal as for the RUN
diode on the RCL 5300 indicator
panel.
The signal follows the RUN diode: constant
signal or periodic signal.
Led 100
The same signal as for the 100 %
diode on the RCL 5300 indicator
panel.
The signal follows the 100 % diode:
constant signal or periodic signal.
Led 90
The same signal as for the 90 %
diode on the RCL 5300 indicator
panel.
The signal follows the 90 % diode: constant
signal or periodic signal.
