Scanreco G2 radio remote control system
20
HMF Technical Service Department
Rev.: 20-13
Signal name
Signal source
Description of signal
RC But 1 (RED)
Activation of the red push button
(pos. 8).
The signal gives the corresponding
functions as when pushing the red press
button on the RCL 5300.
RC But 2 (YELLOW)
Activation of the yellow push button
(pos. 7).
The signal gives the corresponding
functions as when pushing the yellow press
button on the RCL 5300.
RC But 3 (GREEN)
Activation of the green push button
(pos. 6).
The signal gives the corresponding
functions as when pushing the green press
button on the RCL 5300.
RC But 4 (E START)
Activation of tumbler switch no. 2 -
to the left.
In the default settings the signal is used for
starting the engine.
RC But 5 (E STOP)
Activation of tumbler switch no. 2 -
to the right.
In the default settings the signal is used for
stopping the engine.
RC But 6 (RPM P)
Activation of tumbler switch no. 3 -
to the left.
In the default settings the signal is used for
increasing the number of engine
revolutions.
RC But 7 (RPM M)
Activation of tumbler switch no. 3 -
to the right.
In the default settings the signal is used for
reducing the number of engine revolutions.
RC But 8 (FULL)
Activation of tumbler switch no. 1 -
to the left.
High signal for the engine control of the
truck. In case of activation, the number of
revolutions is increased to a predetermined
value.
Configuration N/A.
RC But 9 (AUTO)
Activation of tumbler switch no. 1 -
to the right - on the remote control
box.
High signal for the engine control of the
truck, when a crane function is activated by
the remote control lever.
When the remote control lever is in neutral
position, the signal goes low without delay.
Configuration N/A.
RC But 10 (FLYSH1)
Activation of tumbler switch no. 10
and tumbler switch no. 3 - to the
left.
If there are only 6 remote control levers on
the remote control box and a change-over
valve has been fitted between the Fly-Jib
functions and the extra functions: When
activating the two tumbler switches, the
change-over valve receives a high signal.
Now the remote control lever changes
function from "Fly-Jib - jib" to "rotator".
RC But 11 (FLYSH2)
Activation of tumbler switch no. 10
and tumbler switch no. 3 - to the
right.
If there are only 6 remote control levers on
the remote control box and a change-over
valve has been fitted between the Fly-Jib
functions and the extra functions: When
activating the two tumbler switches, the
change-over valve receives a high signal.
Now the remote control lever changes
function from "Fly-Jib - extension" to "grab".
RC But 12 (OPT 1)
Activation of tumbler switch no. 10
to the right (holding function) or the
left (spring-loaded).
In the default settings the signal is used for
different functions.
Can be used for output signal for optional
extras or as reverser function together with
alternative operation.
RC But 13 (OPT 2)
Like OPT 1.
Like OPT 1.
RC But 14 (OPT 3)
Activation of tumbler switch MICRO
- to the left.
In the default settings the signal is used for
reducing (in steps per activation) the crane
speed.
RC But 15 (OPT 4)
Activation of tumbler switch MICRO
- to the right.
In the default settings the signal is used for
increasing (in steps per activation) the
crane speed after a previous reduction.
