Scanreco G2 radio remote control system
27
HMF Technical Service Department
Rev.: 20-13
Menu item in CGW 5355
Configuration
Description of the function
1.1.1.1.2.8 - Valve sensing
ENT
- Configuration of remote control levers.
1.1.1.1.2.8.1 - Lever function
ENT
- Configuration of the position of the control
levers on the remote control box.
1.1.1.1.2.8.1.1 - Lever setup 1
ENT
- Select the first of several possible
configurations.
1.1.1.1.2.8.1.1.1 - Description
SET, select Crane
- Configuration of crane functions.
1.1.1.1.2.8.1.1.2 - Active
SET, arrow down
- A cross (ticked off) activates the configuration.
1.1.1.1.2.8.1.1.3 - Mode
SET, select Crane
- The configuration is activated in crane mode.
1.1.1.1.2.8.1.1.4 - Activation 1
SET, select Std
- The configuration lies directly on the remote
control levers.
1.1.1.1.2.8.1.1.5 - Activation 2
SET, select OFF
- No other operation on the remote control box
necessary to activate the configuration.
1.1.1.1.2.8.1.1.6 - Lever 1
SET, arrow down
- Select the crane function you wish to operate
from the first control lever from the left (or no
crane function).
1.1.1.1.2.8.1.1.7 - Lever 2
SET, arrow down
- Select the crane function you wish to operate
from the second control lever from the left.
Etc.
SET, arrow down
- Select all relevant remote control levers.
1.1.1.1.2.8.2 - Lever invert
ENT
- The function of the remote control lever is
inverted.
1.1.1.1.2.8.2.1 - Slew 
SET, arrow up
- A cross (ticked off) indicates that the remote
control lever for the slewing movement has
been inverted.
1.1.1.1.2.8.2.2- Boom 
SET, arrow up
- A cross (ticked off) indicates that the remote
control lever for the boom movement has been
inverted.
Etc.
SET, arrow up
The function can be changed for the functions
you require.
1.1.1.1.2.10 - Function speed
ENT
- Adjustment of the speeds of the crane
functions.
1.1.1.1.2.10.1 - Load HDL
ENT
- Adjustment of the crane and HDL speeds.
---------------------
-------------------
--------------------------------
1.1.1.1.2.10.1.1 - Slew
ENT
- Adjustment of the slewing function.
1.1.1.1.2.10.1.1.1 - C.S. CCW
SET, type number (%)
- Speed for the "slew-left" function, ENT.
1.1.1.1.2.10.1.1.2 - C.S. CW
SET, type number (%)
- Speed for the "slew-right" function, ENT.
1.1.1.1.2.10.1.1.3 - HDL CCW
SET, type number (%)
- The HDL speed, "slew-left", ENT.
1.1.1.1.2.10.1.1.4 - HDL CW
SET, type number (%)
- The HDL speed, "slew-right", ENT.
1.1.1.1.2.10.1.1.5 - Start load
SET, type number (%)
- The load moment by which the proportional
HDL is activated, ENT.
1.1.1.1.2.10.1.1.6 - Full load
SET, type number (%)
- The load moment by which the proportional
HDL is fully activated.
1.1.1.1.2.10.1.1.7-F.curveCCW
SET, type number (%)
- Regulation of the oil flow for "slew-left". The
higher value, the more progressive is the
regulation curve in relation to the movement of
the remote control lever.
1.1.1.1.2.10.1.1.8 - F.curve CW
SET, type number (%)
- Regulation of the oil flow for "slew-right". The
higher value, the more progressive is the
regulation curve in relation to the movement of
the remote control lever.
---------------------------
---------------------
------------------------------------------
1.1.1.1.2.10.1.2 - Boom
ENT
- Adjustment of the boom function.
Etc.
SET, arrow up
- As indicated for the slewing movement, it is
possible to make adjustments for the other crane
functions.
