Scanreco G2 radio remote control system
32
HMF Technical Service Department
Rev.: 20-13
1.1.1.1.1.25.2.5.5 - 3A, K1.9
SET, arrow down
- Left rear stabilizer leg "up/down" on output terminal
K1.9: STB 6
1.1.1.1.1.25.2.5.6 - 3B, K1.11
SET, arrow down
- Right rear stabilizer leg "up/down" on output
terminal K1.11: STB 8
1.1.1.1.1.25.2.5.7 - 4A, K1.13
SET, arrow down
- Right rear stabilizer beam "extend/retract" on output
terminal K1.13: STB 4
1.1.1.1.1.25.2.5.8 - 4B, K1.15
SET, arrow down
- Right front stabilizer beam "extend/retract" on output
terminal K1.15: STB 3
1.1.1.1.1.25.2.5.9 - 5A, K3.1
SET, arrow down
- Left rear stabilizer beam "extend/retract" on output
terminal K3.1: STB 2
1.1.1.1.1.25.2.5.10 - 5B, K3.3
SET, arrow down
- Left front stabilizer beam "extend/retract" on output
terminal K3.3: STB 1
1.1.1.1.1.25.2.6 - Source Setup
SET, arrow
down
- Setting up the signal type for the individual output
terminals for stabilizer functions.
1.1.1.1.1.25.2.6.1 - K1.1
SET, arrow down
- Signal type for output terminal K1.1: Digital
1.1.1.1.1.25.2.6.2 - K1.3
SET, arrow down
- Signal type for output terminal K1.3: Digital
1.1.1.1.1.25.2.6.3 - K1.5
SET, arrow down
- Signal type for output terminal K1.5: Digital
1.1.1.1.1.25.2.6.4 - K1.7
SET, arrow down
- Signal type for output terminal K1.7: Digital
1.1.1.1.1.25.2.6.5 - K1.9
SET, arrow down
- Signal type for output terminal K1.9: Digital
1.1.1.1.1.25.2.6.6 - K1.11
SET, arrow down
- Signal type for output terminal K1.11: Digital
1.1.1.1.1.25.2.6.7 - K1.13
SET, arrow down
- Signal type for output terminal K1.13: Digital
1.1.1.1.1.25.2.6.8 - K1.15
SET, arrow down
- Signal type for output terminal K1.15: Digital
1.1.1.1.1.25.2.6.9 - K3.1
SET, arrow down
- Signal type for output terminal K3.1: Digital
1.1.1.1.1.25.2.6.10 - K3.3
SET, arrow down
- Signal type for output terminal K3.3: Digital
1.1.1.1.1.25.2.7 - Min. Current
ENT
- Setting up the minimum current for the individual
output terminals.
1.1.1.1.1.25.2.7.1 - K1.1
SET, type value
- Minimum current for "slew-right": 0%.
1.1.1.1.1.25.2.7.2 - K1.3
SET, type value
- Minimum current for "slew-left": 0%
1.1.1.1.1.25.2.7.3 - K1.5
SET, type value
- Minimum current for "boom-down": 0%
1.1.1.1.1.25.2.7.4 - K1.7
SET, type value
- Minimum current for "boom-up": 0%
1.1.1.1.1.25.2.7.5 - K1.9
SET, type value
- Minimum current for "jib-up": 0%
1.1.1.1.1.25.2.7.6 - K1.11
SET, type value
- Minimum current for "jib-down": 0%
1.1.1.1.1.25.2.7.7 - K1.13
SET, type value
- Minimum current for "extension-out": 0%
1.1.1.1.1.25.2.7.8 - K1.15
SET, type value
- Minimum current for "extension-in": 0%
1.1.1.1.1.25.2.7.9 - K3.1
SET, type value
- Minimum current for "rotator-right": 0%
1.1.1.1.1.25.2.7.10 - K3.3
SET, type value
- Minimum current for "rotator-left": 0%
1.1.1.1.1.25.2.8 - Max. Current
ENT
- Setting up the maximum current for the individual
output terminals.
1.1.1.1.1.25.2.8.1 - K1.1
SET, type value
- Maximum current for "slew-right": 100%
1.1.1.1.1.25.2.8.2 - K1.3
SET, type value
- Maximum current for "slew-left": 100%
1.1.1.1.1.25.2.8.3 - K1.5
SET, type value
- Maximum current for "boom-down": 100%
1.1.1.1.1.25.2.8.4 - K1.7
SET, type value
- Maximum current for "boom-up": 100%
1.1.1.1.1.25.2.8.5 - K1.9
SET, type value
- Maximum current for "jib-up": 100%
1.1.1.1.1.25.2.8.6 - K1.11
SET, type value
- Maximum current for "jib-down": 100%
1.1.1.1.1.25.2.8.7 - K1.13
SET, type value
- Maximum current for "extension-out": 100%
1.1.1.1.1.25.2.8.8 - K1.15
SET, type value
- Maximum current for "extension-in": 100%
1.1.1.1.1.25.2.8.9 - K3.1
SET, type value
- Maximum current for "rotator-right": 100%
1.1.1.1.1.25.2.8.10 - K3.3
SET, type value
- Maximum current for "rotator-left": 100%
1.1.1.1.1.25.2.9 - Ignore Dump
ENT
- Setting up the output terminals, whether they are to
be active even if the RCL goes into stand by mode.
1.1.1.1.1.25.2.9.1 - K1.1

- Active in case of stand by (not ticked off).
1.1.1.1.1.25.2.9.2-12

- All the above-mentioned terminals must be active in
stand by mode (not ticked off).
1.1.1.1.2.8 - Valve sensing
ENT
- Configuration of remote control levers.
1.1.1.1.2.8.1 - Lever function
ENT
- Configuration of the position of the control levers on
the remote control box.
1.1.1.1.2.8.1.1 - Lever setup 1
ENT
- Select the first of several possible configurations.
1.1.1.1.2.8.1.1.1 - Description
SET, arrow down
- Configuration of stabilizer functions: select
Stb.Control.
1.1.1.1.2.8.1.1.2 - Active
SET, arrow down
- A cross (ticked off) activates the configuration.
