LED Indicators 21
Doc: HMSI-168-92 Rev: 3.00Netbiter EasyConnect Gateway User Manual
3.3.2 Serial Status
IndicatesdatatrafficontheRS‐232,RS‐422and RS-485 serial ports as well as GPRS traffic.
3.3.3 Ethernet Activity
3.3.4 Link
Indication Meaning
Green (flashing) Receiving serial packet
Red (flashing) Transmitting serial packet
Orange (steady) Unit is starting up
Indication Meaning
Green (flashing) Receiving Ethernet packet
Indication Meaning
Green (steady) 10 Mb/s Ethernet network detected
Orange (steady) 100 Mb/s Ethernet network detected
