Doc: HMSI-168-92 Rev: 3.00Netbiter EasyConnect Gateway User Manual
2.5 Power
! Makesurethatthepowersupplyiscorrectlyconnected.Connectingwithreversepo‐
larityorusingthewrongtypeofpowersupplymaydamagetheunit.
Netbiter EC150 and EC250
Connect9–24VDCtoVin+(EC150)orV+(EC250),andconnectgroundtoGND.
NetbiterEC150canalternativelybepoweredby9–2 4VAC.
Netbiter EC220
Connect9–24VDCto+VDC,andconnectgroundtoGND
Netbiter EC310/350
Connect12–48VDCto+(plus),andconnectgroundto‐(minus).
