11.2 Specifications EC150 & EC220
Netbiter EC150 Netbiter EC220
Order code NB1001 NB1000
Ethernet 10/100 Mbit/s -
GPRS - Quad band GPRS Class 12
850/900/1800/1900 MHz
Alarms Email, SMS Email, SMS
Relay output
(max 24 V AC/DC, 1 A)
-1
Digital inputs
(isolated max 24 VDC)
22
Analog inputs - 2 inputs (PT100, 0–10 V or 0–20 mA)
Resolution: 11.25 bit
(raw value 0–2400)
Input tolerance 0–10 V: R=1.55 %, A/D=2 mV
Input tolerance 4–20 mA: 2.14 %, A/D=2 mV
Analog output (0–10 V) - 1
Serial port #1 RS-232 up to 115.2 kbit/s RS-232 up to 115.2 kbit/s
Serial port #2 RS-232/RS-485 up to 115.2 kbit/s (isolated) RS-485 up to 115.2 kbit/s (isolated)
Antenna connector - SMA female
Protocols Modbus-RTU,
ASCII, TCP/IP
Modbus-RTU
Connected devices 32 16
Baud rates 300–115200 baud 300–115200 baud
Wall mounting No Yes
DIN rail mounting Yes Yes (optional)
Dimensions (WxDxH) 90 x 70 x 58 mm 92 x 115 x 25 mm
Operating temperature -40 to +65 °C -30 to +65 °C
Storage temperature -40 to +85 °C -40 to +85 °C
Housing class IP20 IP20
Power supply 9–24 V DC or AC 9–24 V DC
Power consumption 2 W 2 W
Certifications
CE, ROHS
CE,
C
UL
US
, FCC/IC, PTCRB
