HMS Netbiter EasyConnect Series - Specifications EC250, EC310 & EC350

Technical Specifications 57
Doc: HMSI-168-92 Rev: 3.00Netbiter EasyConnect Gateway User Manual
11.3 Specifications EC250, EC310 & EC350
Netbiter EC250 Netbiter EC310 Netbiter EC350
Order codes NB1003 NB1007 NB1005 (NB1008 - Without antenna)
Ethernet 10/100 Mbit/s 10/100 Mbit/s
Mobile communication Quad band GPRS Class 12
850/900/1800/1900 MHz
N/A
5-band 3G/UMTS (WCDMA/FDD): 800/850, 900,
1900, 2100 MHz
Quad-band GSM/GPRS: 850, 900, 1800, 1900 MHz
Alarms Email, SMS Email, SMS
Relay output
(max 24V AC/DC, 1A)
N/A 1
Digital inputs 2, isolated max 24 VDC 2, dry contact type
Analog inputs N/A 4 inputs, all supporting 0–10 V or 0–20 mA.
Current: 0–20 mA, R=3.3 %, A/D=0.1 mV+0.15 %
Voltage: 0–10 VDC, R=1.7 %, A/D=0.1 mV+0.15 %
Support for PT100 on AI1 and AI3. Sensor range -50 to +150 °C.
16-bit resolution.
Serial port #1 RS-232 up to 115.2 kbit/s RS-232 up to 115.2 kbit/s
Serial port #2 RS-485 up to 115.2 kbit/s RS-485 up to 115.2 kbit/s
Antenna connector SMA female N/A SMA female
Protocols Modbus-RTU, ASCII, TCP Modbus-RTU, Modbus TCP. EtherNet/IP
Connected devices 32 32
Baud rates 300–115200 baud 1200–115200 baud
Wall mounting No Yes
DIN rail mounting Yes Yes (optional)
Dimensions (WxDxH) 90 x 70 x 58 mm 135 x 92 x 27 mm
Operating temperature -30 to +65 °C -40 to +65 °C
Storage temperature -40 to +85 °C -45 to +85 °C
Housing class IP20 IP20
Power supply 9–24 VDC 12–48 VDC
Power consumption 3 W 4.5 W (typical) 6 W (maximum)
Certifications CE
RoHS
C
UL
US
FCC/IC (Pending)
PTCRB (Pending)
CE
RoHS
C
UL
US
ATEX/Haz.Loc (Pending)
CE
RoHS
C
UL
US
Tele c
JATE
FCC
IC
PTCRB
RCM
ATEX/Haz.Loc (Pending)
