HMS Netbiter EasyConnect Series - Installation; Netbiter EC150; EC250

Doc: HMSI-168-92 Rev: 3.00Netbiter EasyConnect Gateway User Manual
Installation 5
1. Installation
1.1 Netbiter EC150 / EC250
DIN Rail Mount
NetbiterEC150andNetbiterEC250aresupplied
readyformountingonaDINrail.
Mounting
1. Lowertheunitontotheupperlipoftherail.
2. Presstheunittowardstherail.Itwillsnap
intoplaceonthelowerlip.
Removing
1. Insertaflat‐headscrewdriverintotheslot‐
tedtabon
thebottomoftheunitandpullthe
tabgentlydownwards.
2. Pullthelowersideoftheunitfreeoftherail.
3. Lifttheunitfromtherail.
